SP-Y770 1.0

1. Product size L*W*H (mm): 1600*700*625 (±5mm) (closed), 1600*700*1275 (±5mm) (expanded)
2. Material: The desktop is made of E1-grade environmentally friendly high-density board, the thickness of the high-density board is not less than 25MM, and the high-density board has been treated with insect-proof and anti-corrosion chemicals, with high strength, good rigidity, no deformation, and reasonable specific gravity; the outer surface of the high-density board is treated with medium-density fiberboard powder spraying technology, without edge sealing, and all edges of the desktop board are designed in an arc shape, which is beautiful and generous; the surface of the lecture table, including the edge of the user side, adopts an arc chamfer design to prevent collision;
3. The front baffle, left and right baffles, chassis and cabinets are made of 1.0-1.5mm cold-rolled steel plates. All sheet metals are acid-washed, phosphated and sprayed, and then high-temperature baked to prevent rust and spray outdoor powder;
4. The products have passed the test of the antiviral activity test of cold-rolled steel frames. The detection basis and method are ISO 21702: 2019, for experimental virus: human coronavirus, antiviral test of host MRC-5 cells, analysis of test results, antiviral activity value, ≥0.6, antiviral activity rate ≥76.4%; Provide a test report with CNAS or CMA logo (original copy or scanned copy with red seal).
5. The lifting stand of the lecture table is made of high-quality SPCC cold-rolled steel. The stand is installed on the desktop with an embedded installation method. The appearance is hole-free and oil-free, which is cleaner and tidier. The grounding part of the stand adopts an arc design to prevent users from being hit. The stand is pickled, phosphated and sprayed, and then baked at high temperature, which can effectively prevent rust.

Consultation

Functional Features Technical Indicators Overall Dimension

1. Function: The lecture table adopts a three-section dual-motor lifting tripod, the desktop height is electrically adjustable, the minimum desktop height is 610mm, the maximum is 1260mm, the dynamic load of the lifting motor is ≤70KG, the static load is ≤240KG, the motor adopts a super anti-slip design, and the motor lifting speed is ≥40mm/s;
2. The lifting tripod motor controller adopts a wide voltage 100-240V universal design, and the standby power consumption is designed to be <0.5W. The motor controller integrates a high-precision collision sensor, including a gyroscope, which is super sensitive and triggers accurately when encountering obstacles. The motor controller has a complete protection mechanism, including over-temperature and overload protection. The controller is controlled by sophisticated software, and the height of the legs is error-free after 10,000 times;
3. The lifting motor is controlled by a hand controller, which has an integrated LCD screen to display the desktop height and 3 preset height modes. Users can add the required height at any time and restore it to the preset height with one button, which is convenient for operation; dual DC33V output, with RJ45 interface;
4. The upper layer of the lecture table is reserved for the installation of the universal arm bracket of the monitor. It is recommended to install a 10-32-inch monitor. The monitor bracket is made of aviation aluminum, with a load-bearing capacity of ≤9KG, and the monitor can be adjusted at any angle. The upper desktop of the lecture table is equipped with an embedded module, with 2 square power sockets, 1 audio interface, 1 USB interface, 1 HDMI interface, and 1 network port, which are convenient for users to use;
5. The upper desktop of the lecture table can be equipped with a lifting high-definition camera, which has a main photosensitive pixel of 8 million, an output resolution of 3264*2448, a clarity of more than 1200 lines in the center, and more than 900 lines around (1:1 size dynamic, static observation), video output format YUY2, MJPG, interface USB2.0 supports USB3.0, working dynamic current <310 mA, standby current <100 mA;
6. The lower left side of the lecture table can be equipped with a computer host chassis, which is convenient for users to place the computer host; a 1.4m plastic cable management tank chain is reserved under the desktop to facilitate users to organize and fix cables.
7. A 2U cabinet can be optionally installed on the lower right side of the desk to leave enough leg room for the user. The cabinet bottom plate has square holes to facilitate the wiring of the cabinet.

8. Provide legal certification documents of the product source channel (including but not limited to agency agreement, original factory authorization,

etc.) and the original factory's three-year after-sales service commitment letter;
